Instruction for use
43
fig. 33 – the correct position of the
hook
fig. 30 – Anchoring point for towing
fig. 31 – Anchoring point for towing
3.15 STOWING MINIDUMPERS
WARNING: Do not stow the machine with a person on it or an accessory.
WARNING: Use a stowing method that is compatible with the weight of the
machine and that complies with current standard
Check the marking on the stowing accessory to know its LC¹.
If the marking on the accessory is lacking or damaged, do not use it if you
do not know its LC¹
WARNING: If other methods of stowing are used, Cormidi does not guaran-
tee the stowing of the machine
The driver has to make sure that the angle (α) and (ß) are determined so
there is no deviation of the stowing accessories
fig. 32 Anchoring points for transport
