Instruction for use
41
use suitable means of lifting to load it onto a means of transport.
The machine is equipped with 4 rings for lifting each one with a capacity of
7.000N (700kg) for a total of 28.000N (2.800kg).
The position of each hook is indicated with a label like the one shown in the fig.
26
To do this operation safely you should use, as tools of lifting, 4 ropes with
hooks, CE compliant; the two front ropes are 200cm of length, and the two rear
ropes are 200cm of length, in the following way:
Disconnect the battery, turning the device to cut off battery;
Empty the fuel tank and close the plug;
Fix the lifting hooks exclusively to the anchoring points that were pre-
scribed by the manufacturer (fig. 27);
Never lift the machine with someone on it or on an accessory.
Never walk under or beside a machine that is suspended
fig. 27 – Anchoring points to lift the machine fig. 28– correct position
Stick firmly to the floor of the means of transport through the chain approved
Cormidi (Cod. C0260.00.3) purchased from authorized dealers Cormidi), con-
necting more with the points set as in Fgure 29.
WARNING: Raise the machine by hooking it exclusively to the rings predis-
posed for this purpose: the anchoring of the machine in other points can
cause breakage with the consequent fall of the machine and can cause serious
harm to persons.
