ABS 2.0 Operator’s Manual
Publication Number: 621058590OPR - 44 - © 2019, Cornelius Inc.
11.
Reinstall the diffuser by pushing it upward and
a
ligning the diffuser tabs in place
Figure 99.
12.
Reinstall the outer housing in the unit by rotating
it
in the clockwise direction.
NOTE: Tabs must be aligned & apply
u
pward force while twisting to avoid
cross threading.
Figure 100.
13.
Disconnect the sanitizing f
ittings and re-connect
the standard BIB connectors to the syrup boxes
Figure 101.
14.
Flush syrup through every product line. Use the
sele
ction screen to toggle flow on/off by
selecting each brand, up to 4 at one time.
Continue until brands are flowing freely.
Figure 102.
15.
Great job cleaning your ABS 2.0! This will keep
your ABS
2.0 running great!
Monthly clean procedure success
fully finished.
Figure 103.
Table 30. Nozzle Cleaning (Continued)
Step Action Figure
