3 Description
Operator manual: Postmix tower
Ribbon
14
Cornelius Deutschland GmbH
Document no. TD0000000
Version: 19/10/2017, Index 3
The dispensing nozzle assembly comprises the following components:
1. Nozzle housing
2. Diffusor
3. Diffusor seal
The drain set assembly comprises the following components:
1. Drain fitting
2. O-ring
3. Flat seal
4. Fastening nut
5. Tube
6. Tubing clamp
7. Insulation
Notice!
The diffusor seal may only be removed and re-
placed by an expert.
2
3
1
Figure 2
2
1
3
4
5
6
7
Figure 3
