3.4.3 Connections
Connection Type/pin assignment
Carbonated water inlet
3/8 inch inside diameter, 1/2 inch outside
diameter
Carbonated water return
3/8 inch inside diameter, 1/2 inch outside
diameter
Still water inlet
1/4 inch inside diameter, 3/8 inch outside
diameter
Syrup inlets
1/4 inch inside diameter, 3/8 inch outside
diameter
Flavour shot inlets
1/4 inch inside diameter, 3/8 inch outside
diameter
Drain set 1 inch inside diameter
