Operator manual: Postmix tower
Ribbon
17
Cornelius Deutschland GmbH
Document no. TD0000000
Version: 19/10/2017, Index 3
3.3 Touchscreen/software
1. “BRANDS”
2. “FLAVOUR” (flavour shot)
3. “SODA” (carbonated water)
4. “POUR”
5. Cup sizes
1. PIN input
1. “VMC Settings” (virtual machine control settings)
2. “HMI Status” (user interface status)
3. “Software & UI Update”
(software & user interface update)
4. “Critica_Aws”
5. “Wi-Fi”
6. “Ethernet”
7. “Drink Counter”
8. “System Log”
1
34
2
5
Figure 5
Figure 6
2
1
3
4
5
6
7
8
Figure 7
