Description
Cornelius Deutschland GmbH
Document no. TD2005100
Version 15/03/2019, Index 0
Installation and service manual Dispensing valve
SFV1
8
3.3 How the dispensing valve works
A beverage is dispensed by opening the outlet in the respective dispensing valve.
The valve controller works in accordance with the buttons on the control panels, which are actuated on the respective dispensing
valve, or the dispensing lever.
The syrup or concentrate, as well as the soda, are conducted from the base unit through the block mount into the flow controller,
through the valve head into the dispensing nozzle, where they are mixed. From there, the beverage runs into the cup.
An optional soda lever is available for the dispensing valve SFV1. Actuating the soda lever opens only the soda path in the valve,
so that only soda, without syrup or concentrate, flows through the block mount into the flow controller, through the valve head into
the dispensing nozzle and then into the cup.
3.4 Technical data
NOTICE!
For information on the technical data, please refer to the dispensing valve operator manual; see the document
“Dispensing valve operator manual”, document no.: TD2005000.
