Cornelius SFV1 - Dispensing Valve SFV1 Push Button

Description
Cornelius Deutschland GmbH
Document no. TD2005100
Version 15/03/2019, Index 0
Installation and service manual Dispensing valve
SFV1
6
3.1.2 Dispensing valve SFV1 push button
The dispensing valve SFV1 push button comprises the following components:
Fig. 2
1
2
3
459
8
10
11
12
6
7
1 Valve cover rear
2 Flow controller
3 Flow controller seal
4 Block mount
5 Block mount seal
6 Baffle with diffusor
7 Outlet nozzle
8 Valve head
9 Pull-type solenoid
10 Microswitch
11 Control panel
12 Valve cover front
