Maintenance
Cornelius Deutschland GmbH
Document no. TD2005100
Version 15/03/2019, Index 0
Installation and service manual Dispensing valve
SFV1
14
5.3 Cleaning the valves
NOTICE!
Cleaning the dispensing valve is only possible if the dispensing valve is mounted on a base unit.
A description of how to clean the valve can be found in the relevant base unit installation and service manual.
7. Insert the outlet nozzle with the baffle in the dispensing valve,
making sure that the outlet nozzle is straight.
8. Lock the outlet nozzle in the dispensing valve by turning.
Make sure that the dispensing nozzle is inserted correctly as otherwise the beverage cannot
be dispensed correctly.
Fig. 17
