corob PROsample 200 - Regolazione Dello Sgabello; Caricamento Del Barattolo; Adjusting The Can Shelf Height; Loading The Can

- 28 -
COROB D200
6.3.1 
Mantenendopremuidueboonilaterali,inserirelosgabello
nellaguidaappropriata,inbasealladimensionedelbaraoloda
ulizzare.Rilasciareiduebooniperbloccarelosgabello.

Con   : la posizione dello sgabello deve
esseretaledapermeerealbaraolodispingerelabarradi
aperturadeltappo.
Con :laposizionedellosgabellodeve
esseretaledanonfarinterferireilbaraoloconilmovimento
dell’Autocap, ma deve comunque garanre l’oscuramento
dellafotocellula.
6.3.2 
 
Posizionare il baraolo in
modo da spingere la barra
diaperturadeltappocosìda
provocarnel’apertura.
Posizionare il baraolo
in modo da provocare
l’oscuramento della
fotocellulaA.
A
6.3.1 
Keepingthe two sidebuonspressed, inserttheshelf in the
appropriate guide based on the size of the can to be used.
Releasethetwobuonstolocktheshelfinplace.
WARNING
With:theshelfposionmustbesuchthatitallows
thecan--tobelatelyplaced--topushthecapopeningbar.
With  : the shelf posion mustbe such that
it does not cause the can to interfere with the opening
movementoftheAutocap,butmustanywayensureproper
engagementofthephotocell.
6.3.2 
 
Place the can so as to push
the cap opening bar inward
andthuscauseittoopen.
Place the can so as to make
sure that photocell A is
obscured.
