MULTIFUNCTION PANEL
Fuel level
Fuel tank displacement of 40 L of diesel fuel.
The warning indicator will illuminate when there are 5 litres of fuel left.
Operating Conditions
Voltage supply: From 10 to 16 V DC
Minimum operating voltage supply without reset: 6.5 V dc
Operating temperature margin: -20 °C to 80 °C
Storage temperature margin: -30 °C to 90 °C
General specication
Rated voltage: 12 V dc
Test voltage: 13.5 ± 0.1 V dc
Maximum current consumption: < 300 mA @ 13.5 V (Indicators and back lights active)
Current consumption at rest: < 300 μA (without turning on the ignition key)
