WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
CANOPY
SEATS (REMOVAL)
1. Remove the two screws (1) located in each of the two brackets
underneath the seat.
2. Remove the seat.
TECHNICAL INFORMATION
Screw tightening torque: 24 Nm
ROOF (REMOVAL)
1. Remove the plugs on the inside.
2. Remove the six screws (1).
3. Remove the roof upwards.
1
1
