CANOPY
FRONT FENDER (REMOVAL)
1. Loosen the twelve screws (1) holding the fender and remove it.
REAR FENDER (REMOVAL
Before you do this, you must lift out the cargo box.
1.
Loosen the six screws (1) holding the fender and remove it.
To remove the left fender you will need to remove the cap from the
fuel tank.
WARNING
COVER THE ORIFICE OF THE FUEL TANK TO
PREVENT ANY OBJECT FROM FALLING INTO IT.
1
1
1
1
1
1
1
