WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
MAINTENANCE
FRONT LOW AND HIGH BEAM LIGHTS AND INDICATORS
(REPLACEMENT)
1. Switch the vehicle off.
2. Open the front hood.
3. Remove the base of the hood (see page 94)
Replacing the low / high beam lamps:
1. Unplug the electrical connector (1) of the lamp you are replacing.
2. Turn the bulb counterclockwise to remove it from its housing.
Replacing the indicator lamps:
1. To replace the indicator lamps, turn the bulb holder bushing (2)
counterclockwise to disconnect it from its housing.
2. Turn the lamp and separate it from the bushing.
TECHNICAL INFORMATION
Low and high beam headlamps:
HB3 12V 60W, Ref. 09180040003.
Indicator lamp 12V 21W, Ref. 08000960000
1
2
