CORVUS TERRAIN DX4 PRO - Default Chapter; Table of Contents

4
Page
WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
Notes
General information
Introduction
Legal notices
Cautions and warnings
Safety regulations
Preliminary warnings
“Work methodology’’ recommendations
Vehicle identication
Tooling table
Generic table of tightening torques
Specic table of tightening torques
Specications
Multifunction panel
Maintenance
Safety regulations
Maintenance standards
Service chart
Maintenance
Raising the vehicle
Underbody protector
Wheel dismounting/mounting
Engine idling speed
Air lter - cleaning
Engine oil - check
Engine oil and lter - change
TABLE OF CONTENTS
6
9
10
10
11
11
12
12
14
15
17
18
19
21
37
38
38
39
40
40
41
41
42
43
44
45
Transmission oil - check
Transmission oil - change
Front differential oil - check/change
4WD locking oil - check/change
Pre-lter - Water separator - cleaning/replacement
Filter - Water separator - cleaning/replacement
CVT assembly
Sliding pulley - maintenance
Driven pulley - assembly
Coolant - check/change
Radiator pipes and connections
Brake uid - check
Brake uid - change
Brake pads - change
Brake pads - check
Battery
Tires
Steering - alignment
Windshield washer uid
Lubrication
Cable adjustment - accelerator, handbrake, gears
Lighting
Front low and high beam lights and indicators
Rear indicators, break and sidelights
Canopy
Front fenders
Rear fenders
46
46
47
48
49
51
53
66
67
68
70
71
72
73
74
75
76
77
81
82
83
86
87
88
89
90
90
