WORKSHOP
MANUAL
We reserve the right to modify the product and the design.
MULTIFUNCTION PANEL
There are 2 push-buttons, MODE and TRIP, and two types of presses, Short (< 2 secs) or long (> 2 secs).
To change the size of the wheel, we access from TRIP 2 mode, pressing MODE for 10 seconds. Once inside the size conguration, pressing the
push-buttons (see table above), increases or decreases the size of the wheel in mm. Keeping the button pressed will make it increase and decrease
rapidly.
To accept the selected value, press MODE and TRIP at the same time, until the screen returns to its normal appearance.
* : The “X’’ marked with an asterisk are special and are explained in the sections on the indicators.
PUSH-BUTTONSINDICATORS NEXT CONDITION
Short MODE Short TRIP Long MODE Long TRIP
X
X
X
X
X*
X*
X
X*
X*
X
“1 YEAR” service
“Km” service
Reset Service
Decrease
Increase
Store size
SERVICE
WHEEL SIZE
