page-30 EVOLUTION COVER
FIGURE 37: SLIDE WITH LIP OUTWARD
FIGURE 38: I-BEAM FINAL POSITIONS
FIGURE 39: C-CHANNELS / I-BEAM INSTALLATION
4.
Slide the end panels on both ends of the
cover. Make sure the I-beams have slid over
the panel on both bottom and top side see
Figure 40.
NOTE
The tapered ends of the panel are toward the end of
the cover.
CAUTION
Make sure that the panels are pushed as far as
possible by hand and are completely inserted in the
I-beam.
FIGURE 40: END PANELS
WARNING
If you have a color panel, make sure the colored
side is on top.
240799 OWNER'S MANUAL REVISION 4
