Periodic Safety Check
5-14 Force FX Electrosurgical Generator C Service Manual
Activation Indicators
Periodic Safety Check
Perform the following safety check every six months to verify that the generator is
functioning properly. Record the test results for reference in future tests. If the generator
fails to meet any of the checks, refer to Chapter 6, Troubleshooting.
Handswitching Footswitching Activation Indicator
Bipolar Close forceps tines
firmly
Press pedal Activation tone sounds –
Bipolar indicator illuminates
blue
Monopolar Press Cut or Coag
button or Close
forceps tines firmly
Press Cut or Coag
pedal
Activation tone sounds – Cut
indicator illuminates yellow
or Coag indicator illuminates
blue
CUSA handpiece
with CEM
nosecone
Press Cut or Coag
button on CEM
nosecone
Press Cut or Coag
pedal
Activation tone sounds – Cut
indicator illuminates yellow
or Coag indicator illuminates
blue – CEM indicator on
front panel illuminates green
when handpiece is properly
connected
Important
When testing RF equipment, follow these test procedures to duplicate manufacturer test data.
Keep test leads to the minimum length usable; lead inductance and stray capacitance can
adversely affect readings. Carefully select suitable ground points to avoid ground loop error in
measurements.
The accuracy of most RF instruments is approximately 1–5% of full scale. Using uncompensated
scope probes causes large errors when measuring high voltage RF waveforms.
Warning
Electric Shock Hazard When taking measurements or troubleshooting the generator, take
appropriate precautions, such as using isolated tools and equipment, using the “one hand rule,”
etc.
Electric Shock Hazard Do not touch any exposed wiring or conductive surfaces while the
generator is disassembled and energized. Never wear a grounding strap when working on an
energized generator.
