Coviden Force FX - Parts List

Generator Assembly
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-5
Parts List
Item Description Part Number
1Chassis, lower 1005777
2Assembly, Footswitch board
See Footswitch Board Components in this section.
1024339
3Cable assembly, line filter
Includes
Cable, filter line ground
Cable, filter line
Tubing, heatshrink black 1/4 ID
Line filter, 10 amp
Fuse, 4A, 5x20 mm Slow Blow
Sleeving, PVC, clear, 11 awg
202 701 890
207 500 723
207 500 543
249 001 002
251 400 007
215 100 074
249 014 012
4Handle, collapsible tray 223 300 054
5Rubber foot 1005706
6 Equipotential ground lug 208 200 141
8 Screw, Phillips M4 x 0.7 x 10 237 050 139
9Sealant, loctite #222 232 301 148
10 Screw, panhead Phillips M4 x 0.7 x 8 mm 237 050 113
11 Washer, lock internal metric M4 253 300 045
12 Screw, panhead Phillips M3 x 0.5 x 12 zinc 237 050 135
13 Washer, lock internal metric M3 253 300 044
14 Screw, panhead M3 x 0.5 x 8 zinc 237 050 149
15 Lockwasher, M6 ext tooth 253 300 000
16 Nut, hex M6 x 10 brass nickel plated 224 300 000
21 Assembly, front panel
See Front Panel Assembly on page 9-7.
202 701 892
22 Assembly, Control board
See Control Board Components on page 9-10.
1004056
