Power Supply/RF Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-19
Power Supply/RF Board Components
34 Tie wire 222 004 001
35 Ties, Cable, wire 222 004 007
Not Shown:
Tubing, heat shrink 3/8 ID 249 001 003
Cable assembly, 6-wire power 1002251
Cable assembly, 3-wire power 207 500 211
Sealant, Locktite 222 232 301 148
Clip relay, 6 pole 213 130 039
Reference
Designator Description Part Number
Capacitors
C1, C90 100 pF ± 5%, 100 V 204 200 452
C2, C43,
C46, C48,
C52, C58,
C65, C71,
C82, C84,
C86, C117,
C118, C156,
C170, C172
.01 µF ± 20%, 50 V 204 200 456
C3, C10,
C11, C22
680 µF, 400 V 204 500 178
Item Description Part Number
