Display Board Seven-Segment LED Replacement
Replacement Procedures
Force FX Electrosurgical Generator C Service Manual 7-7
Display Board Seven-Segment LED Replacement
1. Remove the Display board (observe all warnings and cautions). Refer to Display Board
Replacement on page 7-5.
2. Grasp the seven-segment LED and pull it out of the Display board, taking care not to
bend the pins. Note the orientation of pin 1 (the corner with the small 45° chamfer).
3. Verify that the replacement LED is the correct color (green).
4. Install the new seven-segment LED, making sure that the orientation of pin 1
(designated by the small 45° chamfer) is the same as that of the LED you removed.
5. Reinstall the Display board. Refer to Display Board Replacement on page 7-5.
Fan Replacement
1. Remove the Power Supply/RF board and attached heat sinks (observe all warnings
and cautions). Refer to Power Supply/RF Board Replacement on page 7-26.
2. Disconnect the fan connector from the Power Supply/RF board.
3. Turn the Power Supply/RF board over, and remove the four screws and nuts that
secure the fan to the board.
4. Position the new fan on top of the Power Supply/RF board and install the four nuts
and screws that secure it to the board.
5. Connect the fan connector to J4 on the Power Supply/RF board.
6. Reinstall the Power Supply/RF board and attached heat sinks. Refer to Power Supply/
RF Board Replacement on page 7-26.
