Control Board Components
9-10 Force FX Electrosurgical Generator C Service Manual
Control Board Components
Display Board Components
Reference
Designator Description Part Number
1 Programmed effect mode controller PCB 1001936
BT1 Battery 250 020 028
U9 IC, programmed T_ON ASIC 210 730 249
Reference
Designator Description Part Number
Capacitors
C1, C2 .01 µF ± 20%, 50 V 204 200 456
C3, C4, C5,
C6
.1 µF ± 20%, 50 V 204 200 460
C7, C8 47 µF ± 10%, 20 V 204 200 558
LEDs and Lamps
D1 LED, green 0.2 dia. 239 750 063
LP1, LP2, LP3,
LP4, LP5, LP6,
LP7, LP8, LP9,
LP10, LP11,
LP12
Lamp 215 200 085
Transistors
Q1, Q2, Q3 FET N-CH 1A, 100 V 239 200 027
Resistors
R1, R2, R3,
R4
16
: ± 5%, 1/2 W 234 014 072
