Bipolar Instrument Receptacle
2-4 Force FX Electrosurgical Generator C Service Manual
Bipolar Instrument Receptacle
You can connect either a footswitching or handswitching bipolar instrument to the
Bipolar instrument receptacle.
Connect a footswitching instrument with a two-pin connector.
or
Connect a handswitching instrument with a three-pin connector.
Caution
Connect accessories to the proper receptacle type. In particular, bipolar accessories
must be connected to the Bipolar Instrument receptacle only. Improper connection
may result in inadvertent generator activation or a REM contact quality monitor
alarm.
