Inspecting the Generator
Troubleshooting
Force FX Electrosurgical Generator C Service Manual 6-3
6. Check the Patient Return Electrode receptacle for a broken pin or an obstruction. If the
receptacle is damaged or obstructed, replace the REM module. Refer to Front Panel
REM Module Replacement on page 7-11.
Inspecting the Internal Components
Equipment required
• Phillips screwdriver
1. Remove the five screws that secure the cover to the chassis. Lift the cover off the
chassis. Save the cover and screws for reinstallation.
2. Verify that all connectors are firmly seated.
3. Inspect each board for damaged components, wires, cracks, and corrosion.
•If you find evidence of damage on the Control board, Display board, or Footswitch
board, replace the board. Refer to Control Board Replacement on page 7-4,
Display Board Replacement on page 7-5, or Footswitch Board Replacement on
page 7-8.
• If you find evidence of damage on the Power Supply/RF board, replace the board
only if the damage is severe. Refer to Power Supply/RF Board Replacement on
page 7-26.
4. To reinstall the cover, position the cover above the chassis and slide it down. Install the
five screws that secure the cover to the chassis.
Caution
The generator contains electrostatic-sensitive components. When repairing the generator, work at
a static-control workstation. Wear a grounding strap when handling electrostatic-sensitive
components, except when working on an energized generator. Handle circuit boards by their
nonconductive edges. Use an antistatic container for transport of electrostatic-sensitive
components and circuit boards.
