Coviden Force FX - Footswitch Board Components

Footswitch Board Components
9-12 Force FX Electrosurgical Generator C Service Manual
Footswitch Board Components
Reference
Designator Description Part Number
Capacitors
C1, C2, C12,
C13, C14,
C16, C17,
C18, C21,
C29, C30,
C31, C32,
C33
.01 µF ± 10%, 100 V 204 200 457
C3, C4, C5,
C6, C7, C8,
C15, C19,
C20, C22,
C23, C24,
C25, C26,
C28, C34,
C36, C37
0.1 µF ± 10%, 100 V 204 200 509
C9, C10, C27 22 µF ± 20%, 25 V 204 600 063
C11 1 µF ± 20%, 50 V 204 200 464
C35 .022 µF ± 10%, 100 V 204 200 501
C38, C39,
C40, C41,
C42, C43,
C44, C45,
C46
.01 µF ± 10%, 500 V 1000293
Diodes
D1, D2 1N4148 239 014 000
Transistors
Q1 FET TN2404KL 239 200 097
Resistors
R1, R2, R3,
R4, R7, R9
10 k
: ± 5%, 1/4 W 234 024 087
