Coviden Force FX - Page 221

Footswitch Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-13
R5, R18, R19,
R31
10 k: ± 1%, 1/8 W 234 201 385
R6 6.8 k: ± 5%, 1/4 W 234 024 083
R10 33.2 k
: ± 1%, 1/4 W 234 201 435
R8, R15, R22,
R23, R26,
R29
2k
: ± 5%, 1/4 W 234 024 070
R11 432 : ± 1%, 1/4 W 234 201 254
R12 Pot, 5 k: 236 200 103
R13, R16,
R20, R24,
R27
1.4 k
: ± 1%, 1/8 W 234 201 303
R14, R17,
R21, R25,
R28
2.15 k: ± 1%, 1/8 W 234 201 321
R30 19.6 k: ± 1%, 1/8 W 234 201 413
R32 200 k
: ± 1%, 1/4 W 234 201 510
R33 5.11 k: ± 1%, 1/8 W 234 201 357
R34 56 k
: ± 5%, 1/4 W 234 024 105
R35 100 k
: ± 5%, 1/4 W 234 024 111
Integrated Circuits
U1 LM339AN 210 300 015
U2 DC/DC converter HPR107 210 750 007
U3, U4, U5 LM 393 N 210 300 011
U6 LM358AN 210 300 013
U7 Audio amp LM386 210 400 019
Reference
Designator Description Part Number
