Left Front Heat Sink and Component Replacement
Replacement Procedures
Force FX Electrosurgical Generator C Service Manual 7-15
Left Front Heat Sink and Component Replacement
Equipment required
• Phillips screwdriver
Remove the Left Front Heat Sink
1. Turn off the generator. Disconnect the power cord from the wall receptacle.
2. Remove the five screws that secure the cover to the chassis. Lift the cover off the
chassis. Save the cover and screws for reinstallation.
3. Remove the Control board.
a. Unlock the connector on the Control board and disconnect the Display board
ribbon cable from the Control board.
b. Carefully slide the Control board straight up through the slots on the heat sinks to
disconnect it from the Power Supply/RF board. Set the board aside in an antistatic
container for reinstallation.
4. Remove the three screws (one plastic and two metal) that secure the support bracket
to the heat sinks. Save the screws and bracket for reinstallation.
5. On the left side of the chassis, remove the two screws that secure the base of the left
front heat sink to the rail under the Power Supply/RF board. Save the screws for
reinstallation.
6. Lift the heat sink to disconnect it from the Power Supply/RF board.
If you plan to replace one or more components on the existing heat sink, go to Replace
Left Front Heat Sink Components on page 7-16.
or
Warning
Electric Shock Hazard To all o w s t ored en e rgy to diss ipat e after power is disconnected, wait at
least five minutes before replacing parts.
Caution
The generator contains electrostatic-sensitive components. When repairing the generator, work at
a static-control workstation. Wear a grounding strap when handling electrostatic-sensitive
components, except when working on an energized generator. Handle circuit boards by their
nonconductive edges. Use an antistatic container for transport of electrostatic-sensitive
components and circuit boards.
Notice
Calibrate the generator after you install a new heat sink or replace components on the heat sink.
Component differences may affect output waveforms. Refer to Calibrating the Generator on
page 5-26, for instructions.
