Display Board Components
Service Parts
Force FX Electrosurgical Generator C Service Manual 9-11
R5, R6, R7,
R8, R9, R10,
R11, R12
0 : 234 500 201
R13, R16 Network 8-pin sip 234 100 184
R14, R15 100
: ± 5%, 1/4 W 234 024 039
R17, R18 1 k: ± 2%, 0.12 W SIP 234 100 134
R19, R20,
R21
270 k
: ± 5%, 1/4 W 234 024 121
Integrated Circuits
U1 2803A 210 800 002
U2, U3 Bicolor display 239 750 076
U6, U10 Display driver 7218A 210 800 025
Integrated Circuits
U4, U5, U7,
U8, U9, U11,
U12, U13
LED 7-segment display HDSP560/green 239 750 071
Miscellaneous (not shown)
Clip, display board 213 130 033
Socket, dip 20-pin gold 208 500 054
Socket, dip 30-pin gold 208 500 055
Socket, I.C. 16-pin 208 121 003
Reference
Designator Description Part Number
