Coviden Force FX - Page 226

Power Supply/RF Board Assembly
9-18 Force FX Electrosurgical Generator C Service Manual
20 Assembly, heat sink, output (right)
Includes
Cable assembly, resistor
Washer, shoulder
Right heat sink
PCB FET
Screw, pnh phh M4 x 0.7 x 8 mm
Screw, panhead Phillips M3 x 0.5 x 12 zinc
Transistor FET BUZ80A
Transistor FET HI-V N-CH
Diode, ultra fast 30 A, 1000 V
Washer, lock internal metric M4
1024532
207 500 540
253 200 061
223 400 675
228 349 000
237 050 113
237 050 135
239 200 020
239 300 044
239 850 038
253 300 045
21 Assembly, heat sink, high voltage (left rear)
Includes
Cable assembly, rectifier
Washer, shoulder
Left rear heat sink
Resistor, MF 150
: ± 5%, 20 W
Screw, panhead Phillips M3 x 0.5 x 12 zinc
Transistor FET N-CH 8 A, 500 V
Diode, bridge 35 A, 400 V
Washer, flat M3.0
Washer, Lock Internal M3
1024531
207 500 212
213 400 057
223 400 674
234 400 251
237 050 135
239 200 022
239 700 058
253 300 004
253 300 044
22 Assembly, heat sink, rectifier (left front)
Includes
Washer, shoulder
Left front heat sink
Resistor, MF 150
: ± 5%, 20 W
Screw, panhead Phillips M2.5 x 04.5 x 10 mm zinc
Diode, Fast Recovery
1024533
213 400 057
223 400 673
234 400 251
237 050 159
239 850 034
23 Panhead Phillips M4 x 0.7 x 20 mm 237 050 130
24 Fuse holder 1000697
25 Bracket, heat sink support 1030417
28 Screw, panhead Phillips M4 x 0.7 x 8 nylon 237 050 143
30 Wire, TS, 20 awg, yellow 255 058 006
31 Sleeving, PVC clear 11 awg 249 014 012
32 Wire, TS, 20 awg, red 255 058 008
33 Washer, lock internal M3 253 300 044
Item Description Part Number
