Coviden Force FX - Page 64

Output Power vs. Resistance Graphs
3-34 Force FX Electrosurgical Generator C Service Manual
Output power vs. impedance for Desiccate coag 120W mode
Open circuit peak voltage vs. output power for Desiccate coag mode
Load Resistance (ohms)
Output Power (watts)
Output Power (watts)
O
pen
Ci
rcu
i
t Pea
k
Vo
l
tage
(
vo
l
ts
)
