30
Step 2 Hang the inverter onto the mounting bracket as shown in Figure
3-9 and Figure 3-10:
(a) Lift mounting: Locate the lifting eyes at the top of the inverter.
Use sling rope or bar (inserted through both lifting eye nuts)
to lift the inverter onto the bracket. The minimum angle
between the two sling ropes should be less than 90 degrees.
(b) Manual mounting: Two people are required to safely lift the
inverter by the grab handle positions marked in Figure 3-10
and mount it onto the bracket.
CAUTION:
The main enclosure of the CPS SCA25KTL-DO/US-208、CPS
SCA50KTL-DO/US-480 and SCA60KTL-DO/US-480 3-Phase
String Inverters is approx 56kg (123.5 pounds). Ensure the
mounting bracket is properly installed and secured before hanging
the inverter on the bracket. It is recommended to have at least 2
people to mount the inverter due to the weight of the equipment.
