41
power measurement; if the PV power increases, further voltage
adjustments in that same direction are performed until the PV power no
longer increases.
Table 3-3 DC Input Specifications (Independent Mode)
Specification
(Independent Mode - per MPPT)
Model
SCA25KTL-DO/US-208
SCA50KTL-DO/US-480
SCA60KTL-DO/US-480
Max PV Power
14.5kW
(Combined ≤ 37.5Kw)
30kW
(Combined ≤ 75Kw)
33kW
(Combined ≤ 90kW)
Max PV Voltage
1000Vdc
1000Vdc
1000Vdc
Start-up
Voltage / Power
330 / 80W
330 / 80W
330 / 80W
Operating Voltage
200-950Vdc
200-950Vdc
200-950Vdc
MPPT Voltage
Range
480-850Vdc
480-850Vdc
540-850Vdc
Maximum PV
Current (Isc x 1.25)
45A
68A
68A
INSTRUCTION:
PV input power from the array may be unbalanced between the three
MPPT zones, however every effort should be made to design within
one string count difference. See Table 3-3.
When designing the PV system ensure each PV string within a single
PV input zone includes the same module type (Mfg and ratings),
same series module count, and same module orientation (tilt and
azimuth) to maximize MPPT performance and energy harvest.
