36
Figure 3-16 Location of the Anti-Theft Padlock
The anti-theft padlock should meet the dimensional requirements
shown in Figure 3-17.
Recommended lock size:
A: Shackle diameter 3~6mm
B: Shackle width 20~50mm
C: Shackle height 20~50mm
Figure 3-17 Dimensions of Anti-Theft Padlock Shackle
B
C
A
