Figure 3-28-2 SCA36/50/60KTL Standard wiring box
NOTICE:
To maximize production, reduce clipping losses, and optimize thermal
performance, the DC input power should be distributed across all
MPPTs as evenly as possible (e.g. difference in number of strings per
MPPT not larger than 1).
Before terminating the PV conductors to the Bypass Terminals, verify
connector specifications (Table 3-9) and always verify polarity to avoid
risk of reverse polarity.
Table 3-9 Connector Specifications
