Advanced operations
5.3.7 Measured value: 4 bytes
It is delivered as a number of 32 bits of floating point (IEEE format).
5.3.8 Temperature: 4 bytes
It is delivered as 32 bits of floating point numbers (IEEE format) expressed in °C.:
5.3.9 Verification of PROFIBUS installation
Using the option INSTALLATION CHECK, it is possible to provoke data sending with the
required values.
1. From the main menu select SYSTEM > CHECK INSTALLATION. Confirm.
2. Select PROFIBUS and confirm.
3. Select the channel to verify and confirm.
Table 5-1Example of datum value and sent bytes
Datum Byte 1 Byte 2 Byte 3 Byte 4
25
41 Hexadecimal
65 Decimal
C8 Hexadecimal
193 Decimal
00
Table 5-1Example of temperature value and sent bytes
Datum Byte 1 Byte 2 Byte 3 Byte 4
25
41 Hexadecimal
65 Decimal
C8 Hexadecimal
193 Decimal
00
