Specifications
Figure 1 Instrument dimensions
EC Directives
Electrical security according to 2006/95/EC
Electromagnetic compatibility according to 2004/108/EC.
Environmental conditions
Working temperature: 0 to 50 ºC (32 to 122 ºF)
Storage temperature: -20 to 65 ºC (-4 to 149 ºF)
Relative humidity < 80 % (non condensing)
Altitude requirements: max. 2000 m (6562 ft) ASL (Above Sea Level)
Enclosure
Protection IP 65 (With rear cover installed, transparent door closed
and connector MP-5 protected.)
Inflammability rate, Glow wire test 650ºC, UL 94 HB.
Material free of halogens
Physical parameters
Weight 1800 g
Dimensions 210 x 215 x 100 mm. (see Figure 1)
MultiMeter 44
ESC
OK
*
IP 65
215
210
100
