Page 36
P469E 1-8E Two Trigger Zones - Where options 1-8 represent zones 9-16 respectively. A zone defined as
two trigger at this address will only cause an activation if one of the following conditions are met;
a
The zone is triggered twice within the two trigger time period as defined by Address P534E,
P535E or P536E
b Any two zones defined as two trigger activate once each within the two trigger time period
as defined by Address P534E, P535E or P536E
c A zone defined as two trigger is left violated for longer than the two trigger time period as
defined by Address P534E, P535E or P536E
P470E 1-8E Zone is 24 Hour - Where options 1-8 represent zones 9-16 respectively. 24 hour zones will
activate whether the panel or partition is armed or disarmed. If an entry delay is also assigned to
a 24 hr zone, the alarm will not trigger unless the zone is in alarm longer than the delay time
programmed. (Default none)
P471E 1-8E Zone is 24 Hour Fire Zone - Where options 1-8 represent zones 9-16. 24 hour Fire zones will
activate whether the panel or partition is armed or disarmed. If an entry delay is also assigned to
a 24 hr Fire zone, the alarm will not trigger unless the zone is in alarm longer than the delay time
programmed. A Fire Zone will cause the output to pulse to differentiate it from a burglar alarm.
(Default none)
P472E 1-8E Zone is 24 Hour Auto-Reset - Where options 1-8 represent zones 9-16. 24 hour Auto-Reset
zones will activate whether the panel or partition is armed or disarmed. If an entry delay is also
assigned to a 24 hr Auto-Reset zone, the alarm will not trigger unless the zone is in alarm longer
than the delay time programmed. An Auto-reset zone will seal automatically when the zone input
is restored back to normal i.e. does not require a code to reset an alarm. (Default none)
P473E 1-8E Day Zones - Where options 1-8 represent zones 9-16 respectively. Day zones are active during
periods where the panel or partitions are disarmed and revert to normal zones during armed
periods (Default none)
P474E 1-8E Continuous Day Zone - Where options 1-8 represent zones 9-16 respectively. The zone acts
as a day zone at all times (Armed and Disarmed) and will operate day alarms but not normal
zone alarms (Default none)
P475E 1-8E Siren Lockout Zones - Where options 1-8 represent zones 9-16
respectively. Zones with siren lockout designation will only
cause their assigned outputs to operate once per armed period.
Led on = zone locked out. (Default none)
P476E 1-8E Access Control door position input - Where options 1-8
represent zones 9-16 respectively. The door position input
becomes a 24 hour alarm zone and will alarm if the “Control” door is forced open or left open too
long. It will also automatically re-lock the door after the “Control” operation has occurred and the
door has been opened then closed again. (Default none)
P477E 1-8E Access Control Request to exit input - Where options 1-8 represent zones 9-16 respectively.
The Request to Exit input will operate the “Control” door output to
release the door and start the Door open Too long Timer. (Default
none)
P478E 1-8E Zone will report multiple activations to communicator - Where
options 1-8 represent zones 9-16 respectively. If this option is
turned off then the relevant zone will only report one alarm to a
monitoring company during any single armed period. If it is turned
on, the zone can send multiple reports if activated more than once
during a single armed period.
P479E 1-8E Zone will be Monitored for Inactivity - Where options 1-8 represent zones 9-16 respectively. A
Zone with this option turned on will be checked to ensure that it is triggered on a regular basis. If
the zone is not triggered within the time period set at P569E then an alarm will be generated as
the detector may have become faulty or could be masked. The timer period as set at address
P569E is only active during the disarmed period. If the timer has started due to inactivity of a
zone input, the elapsed time is remembered at the time of arming and will resume when the
alarm is disarmed.
P480E 1-8E Cannot Arm if Zone is Unsealed - Where options 1-8 represent zones 9-16 respectively. If a
Zone 1 Entry Dela
20
Zone 1 Exit Delay
60
