2.6.6 Peak review
Select this option from the Menu Screen to see the highest level of each gas detected during the
session. The menu offers the choice to display the peak gas level since the Gas-Pro was powered
up , that occurred during the last 8 hours , or during the last 12 hours . There is also an
option to clear current peak readings back to clean air values. The peaks are cleared when Gas-Pro
is turned off.
2.6.7 Settings
The following settings can be altered by the user:
2.6.7.1 User setting
Up to 5 different users can be loaded into Gas-Pro using the Portables Pro PC application.
Double click the operator button to select the function. The screen will display the 5 user selectable
icons (
À to Ä). Single click the operator button until the required user number is highlighted and
then double click to select it. The screen will return to the settings menu and after a few seconds will
display the home screen. Gas-Pro will create an event when the user is changed allowing traceability
of the user.
2.6.7.2 Pump setting
This function, which is only present if the Gas-Pro has an internal pump, allows the user to turn the
pump on or off.
Double click the operator button to select the function. Single click the operator button to highlight
the required symbol (
to turn the pump on or to turn the pump off) and then double click. The
screen will return to the settings menu and after a few seconds will display the home screen.
If a ow plate is attached a ‘sensor covered’ icon will be shown
.
2.6.7.3 Sounder volume
This function allows the user to change the sounder volume.
Double click the operator button to select the function. Single click the operator button to highlight
the required symbol (
for high volume (98dB) or for low volume (95dB)) then double click.
The screen will return to the settings menu and after a few seconds will display the home screen.
