Crowcon Vortex - Table 12: Relay Configurable Properties

Vortex
32
Table 12: Relay configurable properties
Property Configuration
Identity
An 8-character string used to identify the Relay
Output.
Enabled
On/Off. A relay must be enabled and configured to
participate Relays may be removed from the
system by clearing this check box. This is
recommended only when the relay is temporarily
removed, not as a long-term solution.
Output Type
Latching, Non-Latching, Latching Acceptable,
Non-Latching Acceptable, Pulsed, Reset Pulse or
Not Configured. See Table 13.
Any unused relays should be set to Not
Configured.
On Delay Time
The waiting period before the relay is activated.
Where applicable, 0 to 65535 seconds.
Off Delay Time
The waiting period before the relay is deactivated,
except for Pulsed and Reset Pulsed, where it is the
period for which is relay is activated.
Where applicable, 0 to 65535 seconds.
Energisation
Either Normally Energised or Normally De-
Energised The default is Normally De-Energised.
