1 INTRODUCTION
1.1 What this manual is for
This manual describes the installation, configuration and operation of the Vortex gas and fire
detection system and its components.
Some of the functionality described in this manual may not be available with some units.
Contact Crowcon concerning upgrades of existing systems, if required.
1.2 What is Vortex?
Vortex is a modular gas and fire detection system, designed to monitor remote 4-20mA and
conventional loop powered fire detectors. Other devices may be used as advised by Crowcon.
It can operate flexibly assigned and voted relays if pre-set levels of gas are exceeded or if
smoke or fire is detected. These relay outputs may be used to drive audible and/or visible
alarms. The built-in Modbus communications interface allows multiple Vortex systems to be
connected to industry-standard control monitoring systems.
The Vortex system may be mounted in a variety of enclosure; the options are listed in Table 1
Table 1: Vortex options
Vortex. Standard wall-mounted enclosure with display See
Figure 2: Vortex system in Standard Enclosure.
Vortex Rack* Vortex system with a 19-inch rack-mounted
display.
Vortex Panel*.
Vortex DIN* Vortex system with no display.
Options marked * can be supplied as modules to be mounted in your own enclosure.
The system can be supplied pre-configured with detectors and output devices, the
configuration is summarised on the Specification Sheet provided with the system. The
configuration can be modified using the VortexPC software.
1.3 Who should use this manual
You may not need to read the whole of this manual. You will be guided to the sections that
you require.
You should consult this manual if you:
Use the Vortex system for monitoring fire or gases, and respond to alarms
Carry out routine maintenance on the Vortex system and its detectors
Configure the Vortex system
