Crowcon Vortex Installation, Operation And Maintenance

Vortex
50
6.4.2 Power Status
There is a Power Healthy LED on the Display Module, which provides information about the
status of the various power systems.
Table 18: List of Power Status LED codes
Code Fault description
Solid green
Mains power supply is good and the battery
level is
good.
Fast flashing
green
Mains power supply is good but the battery
level is low.
Solid yellow
Mains power supply has failed but the
battery level is
good.
Fast flashing
Yellow
Battery level is low and mains power supply
is disconnected.
Slow flashing
yellow
Battery is discharged, disconnected, faulty
or disconnected for deep discharge
protection.
Unlit Complete power failure or the Power
Monitoring Module cannot be accessed on
the bus.
OPERATION
6.4.3 System Faults
There are several system faults that are indicated by the System Fault LED on the Display
Module.
The Fault LEDs on the Node Controller Module indicate what system error has occurred
using a binary code.
Table 19: List of Node Controller Module LED fault codes
● = lit, ○ = unlit
Code Fault description
○
○
○
No fault.
○
○
●
1 Battery fault.
The battery is seriously discharged or disconnected. Reconnect
or replace the battery. If no battery is fitted, ensure link LK1, on
the power monitor module, is made.
