Vortex
70
Option/Property
Allowed values and explanation
Fire detectors
The current thresholds must be set within the range 0 to 60mA, in the
order Open Circuit < Fire < Short Circuit Reset time Between 0 and
255 seconds. The time that the loop current is removed to reset a
latched fire detector on pressing ACCEPT/RESET after a fire alarm.
Stabilisation time Between 0 and 255 seconds. The time allowed for the
fire detector to stabilise after a reset before coming on line.
Relays
Identity
8-character string used to identify the relay
Enabled On/Off. A relay must be enabled and configured to participate
Type This can be set to Not Configured, Non-Latching, Non-Latching
Acceptable, Latching, Latching Acceptable, Pulsed or Reset Pulse.
Unused relays must be set to Not Configured. Explanations are given in
section 4.5.2.
ON delay time The waiting period before the relay is activated. Where applicable, 0 to
65535 seconds.
OFF delay time The waiting period before the relay is de-activated, except for Pulsed
and Reset Pulsed, where it is the period for which is relay is activated.
Where applicable, 0 to 65535 seconds.
Energisation
Normally Energised or De-energised. See section 4.5.2.
Relay logic
Detector Links
Allow detector alarms and events to be mapped to relay logic, see
section 4.5.3
System Links
Allow the system fault and system sounder to be mapped to relay logic,
see section 4.5.3
Vote Count
The count is between 1 and the number of inputs to the relay, and is the
number of inputs required to trigger the relay. See section 4.5.3.
APPENDICES
APPENDICES
