FrameandBody

Theframeandbodysubsystemincludesthemotorcycle’ssteelframe,theseat,thebodypanels,the
sidestand,thefootpegs,andthefenders.

Therearseatisremovablebyinsertingandtwistingtheignitionkeyintheleftbodypanelbeneaththe
seat.Thetoolkitisstoredbeneath
therearseat.

Thefrontseatisheldinplacebytwo8mmbolts.Therearseatcanberemovedtoprovideaccesstothe
battery.

Theleftbodypanelcanberemovedtoprovideaccesstotheairfilter.

Frameandbodymaintenanceandtroubleshootingguidelinesaresummarized
below.

FrameandBodyMaintenanceandTroubleshooting
Item Symptom Cause VehicleEffect MaintenanceAction
Frame Frameishitorfalls
over
Frameiscurvedor
deformed
Drift Correctorreplacethe
frame
Frameishitorfalls
over
Frameiscrackedor
fractured
Motorcyclecannotdrive Weldorreplacethe
frame
Frameisimpacted
andshockedbyroad
Framewelding
detachment
Shakeordrift Weldtheframe
Sidesupport Deformationor
fracture
Sidesupportis
normalandcannot
return
Noiseandcompromised
parking
Correctorreplacethe
sidesupport
Leftsidecover Impact Leftsidecover
damaged
Compromised
appearance
Replaceorrepairthe
leftsidecover
Rightside
cover
Impact Rightsidecover
damaged
Compromised
appearance
Replaceorrepairthe
rightsidecover
Frontfender Impact Deformationor
breakage
Motorcycledriveswitha
noise
Replacethefront
fender
Rearfender Impact Deformationor
breakage
Motorcycledriveswitha
noise
Replacetherear
fender
Frontandrear
seatcushion
Impact Seatcushion
damaged
Ridingcomfortableness
decreases
Replacethefrontand
rearseatcushion
Frontfootpeg Impact Deformationor
breakage
Compromiseddriving
safety
Replacethefootpeg
Rearfootpeg Impact Deformationor
breakage
Comfort Replacethefootpeg
Rearview
mirror
Impact Deformationor
breakage
Compromiseddriving
safety
Replacetherearview
mirror
Rearrack Impact Deformationor
weldingdetachment
Compromised
placementofitems
Weldorreplacethe
rearrack

 
