FuelSystem

Thefuelsupplysystemconsistsofthefueltank,fuelpump,fuelinjector,fuelfilterandfuelhoses.
ControlledbytheECU,thefuelinjectorspraysappropriateatomizedfuelintotheengine.Thefuel
supplypressureis250kPa.Thefuelshouldbe87octanegasolineorhigher.



The
fueltankisstampedandweldedfrom
0.8mm—l.0mmthicksteelplate.

Thereisafuelfillerportonthetopofthetank,
andthetankhasalockingcap.

Thefueltankcapacityis16L,or4.2gallons
withoutanyofthefueltank’sinternal
componentsinstalled(fuelpump
andfuelgage
sendingunit).Asassembled(withthefuel
pumpandthefuelgagesendingunit),fuel
capacityis3.9gallons.


Thefuelpumpassemblyconsistsofthefuel
pump,fuelpumpsupport,andfuelpressure
regulator.

Thefuelpumpisturbo‐typesingle‐stagefuel
pumpdrivenbya12VDCmotorandcontrolled
bytheECUthroughthepumprelay.Onthe
pumpdischarge,thereisacheckvalve
sothat
thefuelinthetubewillnotflowbacktothe
tankwhentheengineisnotworkingand
enginestartingwillnotbeaffected.



Fuel Pump
