AccessoriesInstallation

TheNorthAmericanRX3configurationisdeliveredfullyassembledexceptforthewindshield,the
mirrors,andthetopcase.Allotheraccessoriesprovidedwiththemotorcyclearealreadyinstalled
whenthemotorcycleisdelivered.Forreference,installationinstructionsfortheguardbars,therear
rack,thetopcase,and
thepanniersareincluded here.

MotorcycleGuardBarInstallation

Installtheforwardguardsfirst.Theforwardmotorcycleguardbarlayoutandrequiredfastenersare
shownbelow.



Startbyinstallingtheupperportionbeneaththefrontfender.ItattacheswithasingleM8×16flange
boltasshowninthe
photosbelow.

