Theprocedureissimilartotheprocedureforreplacingthebrakefluid.Openthemastercylinderby
unscrewingthetwoscrewssecuringthemastercylindercover.Removethemastercylindercoverand
placeitinanareawhereitwillnotbecomecontaminated.Removethecaliperbleedcapandattach
a
smalldiametertubetothecaliperbleedfitting.Routethetubetoareceptacle.Openthecaliper
bleedfittingbyunscrewingitslightly(turnitcounterclockwisetodoso)anddepressthebrakeleverto
pumpbrakefluidoutthroughthecaliperbleedfitting.Priortoallowingthebrakelever
toreturn,close
thecaliperbleedfittingbyturningitclockwise.Addbrakefluidtothemastercylinderas
necessary.Repeattheprocessuntilthebrakefluid exitingthecaliperisfreeofairbubbles.Closethe
caliperbleedfittingandreplacethefittingcap.Addbrakefluidtothe
mastercylindersuchthatthe
upperleveliswithin1/8‐inchofthetop(donotoverfillthemastercylinder).Replacethemaster
cylindercoverandthescrewssecuringittothemastercylinder.

Aftercompletingtheabove,pumptherearbrakepedal(ifyouarebleedingtherearbrake)
oroperate
thefrontbrakelever(ifyouarebleedingthefrontbrake)severaltimes.Operatethemotorcycleto
assuresatisfactorybrakeperformance.

InspectingandReplacingtheBrakeDisks

Youshouldreplaceanybrakediskthatiswornbelowservicewearlimitsorifthediskiswarped.You
can
measurediskthicknessandstraightnesswithoutremovingthewheelfromthemotorcycle.Youwill
needtoremovethewheelifyoureplacethebrakedisk.

Measurethediskthickness.Ifthediskislessthan2 mmthick,
replacethedisk.

Useadialindicatorwiththewheeloffthegroundtomeasuredisk
runout.Spinthewheelandmeasurerunout.Iftherunoutexceeds
0.3mm,replacethedisk.Youonlyneedtodothisif
thediskappears
tobevisiblywarped(whichisnotlikely)orifthebrakespulsatewhen
applied.

Youwillhavetoremovethewheelinordertoreplacethedisk.Theprocedureforwheelremovalis
explainedelsewhereinthisServiceManual.

EachdiskissecuredwithsixAllenbolts.UseblueLoctitewhenreinstallingtheboltsthatsecurethe
brakedisk.

BrakeTroubleshooting

Braketroubleshooting
proceduresaresummarizedbelow.

FrontandRearBrakeTroubleshootingandMaintenance
Item Symptom Cause VehicleEffect MaintenanceAction
Brakepad Reducedbraking
force
Wornbrakepad(s) Longerstopping
distance
Replacebrakepad
