SteeringTroubleshootingandMaintenance
Item Symptom Cause VehicleEffect MaintenanceAction
Handlebar Bent Impact Drift Replacehandlebar
Steelballrace Excessivetightness
ofadjustingnut
Overtightened Sticky
movement
Adjustusingalocking
wrenchuntilsteering
columncanrotate
freelywithnoendplay
betweensteering
columnandframe
Excessiveabrasion,
pitting,dirt,crack
anddamage
Contamination Sticky
movement,
swingand
shakingof
handlebar
whiledriving
Replacewholesetof
steelballandrace
Steeringraceballs Abrasion,
deformation,
damage
Contamination Sticky
movement,
swingor
shakingof
handlebar
whiledriving
Replacewholesetof
steelballandrace
Steeringcolumn Bent Impact Sticky
movement
Replacesteering
column
Swingarm

Theswingarmconnectstherear
wheelandtheframe.The
swingarmconsistsoftherear
fork(i.e.,theswingarm),dust
seal,dustsealcover,bearing
rearforkshaftsleeve,andother
smallparts.Theswingarm
includesshaftbearings.


SwingarmTroubleshooting

Swingarmmaintenanceandtroubleshootingactionsaresummarizedinthe
tablebelow. 

SwingarmTroubleshootingandMaintenance
Item Symptom Cause VehicleEffect MaintenanceAction
Swingarm Deformedswingarm Impact Pullstooneside Replaceswingarm
Fracturedswingarm Impact Pullstooneside Replaceswingarm
Stickyswingarmaction Dustsealssev erely
abradedorworn
Poorrearsuspension
action
Replacedus tseals
andbearings


Swingarm
