CSC RX3 - Battery and Installation

CSCRX3ServiceManual
www.CSCMotorcycles.com
76

ElectricalSystem

Thefunctionoftheelectricalsystemistosupply electricenergyforstartingandrunningthemotorcy cle. 
Theelectricalsystemconsistsofpowersupplypar ts,powerutilizationparts,andcontrolparts.The
powersupplysystemconsistsofthestatorandbattery.Whentheenginedrivesthestatortoreach
a
certainspeed,thestatorwilloutputelectricalenergy.Thisenergypowerstheelectricalequipmentand
chargesthebattery.Thebatteryusesitsstoredenergyforstarting,illumination,signaling,andother
purposes.Thepowerutilizationportionoftheelectricalsystemuseselectricalenergyforlighting,
starting,signaling,accessories,andapplications.
Thecontrolportionoftheelec tricalsystemconsistsof
theelectroniccontrolunit(ECU),therectifier,thestarterrelay,thefuse,thecontrolswitchgear,and
themainelectricalharness.

Yourmotorcyclehasa300‐wattstator,a12Vleadacidbattery,amainharnesstoconductelectrical
energytovarious
motorcyclecomponents,aregulator,connectors,flashers,anECUforcontrolling
enginefunctions,astartermotor,fusesforoverloadprotection,andothercomponents.

Mostofthemotorcycle’smainelectricalcomponentsarelocatedbeneaththerearseat.After
removingtheseatsandtheplasticcoverbeneaththerearseat,thecomponentsare
accessible.The
electricalcomponentlocationsareidentifiedinthephotobelow.



