CSC RX3 - Accessories Connections; Electrical System Components and Locations

CSCRX3ServiceManual
www.CSCMotorcycles.com
78

AccessoriesConnections

TheCSCRX3hastwo12Velectricalaccessoryoutletsundertheseatontheleftsideofthemotorcycle .
Thesearecontrolledbytherighthandlebaraccessoriesswitch.IntheOposition,nopowerisprovided
totheaccessoriesoutlets.IntheA1position,powerisprovidedtoone
oftheaccessoryoutlets;inthe
A2position,powerisprovidedtotheotheraccessoryoutlet.


TheRX3motorcyclerequires160wattsfornormaloperation.140wattsareavailableforaccessories
beyondthoseprovidedwiththemotorcycle.Youshouldmakesurethatthetotalelectricalloadforall
accessories
doesnotexceed140watts.

ElectricalSystemComponentsandLocations

The control system includes the regulator, a flasher relay, a starter relay, an LED relay, two fuse sets
(two20Afusesforthebatterypowercircuitandtwo15Afusesforotherelectricalcomponents),control
switches,themainharness,connectors,lights,
thehorn,andotherparts.Thesecomponentsandtheir
locations are primarily located beneath a cover under the rear seat.To gain access to these
components, remove both seats.Then remove the black plastic cover beneath the rear seat.It is 
securedbyfourbolts.

Allelectricalcomponents,theirlocation,
andaphotographofeachareprovidedinbelow.

Thevoltageregulatorislocatedontheleftframebeneath
theleftforwardbodypanel.

