19

Don’tletthelubegetonthetire,anddon’tshootspraylubricantthroughthespokesandgetthelubeon
therearbrake.Don’tridethemotorcycleforatleast15minutesafterlubingthechain.Thatwillallow
thelubetoseepintothechain.

CSCstocksboth
waxandpetroleumbasedchainlubes(callusat9094450900topurchasetheseitems).

SprocketandChainInspection

TheCSCRX3hasa520O‐ringtypechain,a14toothfrontsprocket,anda44toothrearsprocket.
Ifyoukeepyourchain properlyadjustedandlubed,
thechainandsprocketswilllastmuchlongerthan
theywouldifyoudon’tmaintaintheseitems,buttheystillwon’tlastforever.Youcanexpectthechain
andsprocketstowearmorequicklyifyourideindustyenvironmentsoroffroad.Chainsandsprockets
shouldbereplacedasa
set.Donotreplaceonewithoutreplacingtheotherorrapidwearwillresult.

Removethecountershaftsprocketcoverbyremovingthetwoboltsthatattachittotheengine.You
don’thavetoremovethegearshiftlevertoremovethecountershaftsprocketcover.

TherearethreeAllenbolts
thatsecurethechainguard.Twoarevisibleandeasilyaccessible;thethirdis
hiddenontheforwardportionofthechainguard(onthepartofthechainguardthatisbehindthe
chain).Undothethreeboltsandremovethechainguard.


Afteryouhaveremovedtheseitems,youcansee
thesprocketsandthechain.


